G5A-234PH-DC24 - OMRON Electronics

G5A-234PH-DC24 Details

• Manufacturer Part Number:

  G5A-234PH-DC24

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  0

• Body Breadth:

  9.9 mm

• Body Height:

  8 mm

• Body Length or Diameter:

  16 mm

• Coil Current(DC)-Max:

  0.007 A

• Coil Operate Voltage(DC):

  19.2 V

• Coil Power:

  150 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  3700 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .5A@60VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@30VDC

• Contact Voltage(AC)-Max:

  60 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  5.5 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  16mm X 9.9mm X 8mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  5.5 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
