G5LE-1-DC3 - OMRON Electronics

G5LE-1-DC3 Details

• Manufacturer Part Number:

  G5LE-1-DC3

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  6

• Body Breadth:

  16.5 mm

• Body Height:

  19 mm

• Body Length or Diameter:

  22.5 mm

• Coil Current(DC)-Max:

  0.136 A

• Coil Operate Voltage(DC):

  2.25 V

• Coil Power:

  400 mW

• Coil Release Voltage(DC):

  0.3 V

• Coil Resistance:

  22.5 Ω

• Coil Voltage(DC)-Max:

  3 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  10A@250VAC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  8 A

• Contact (DC) Max Rating R Load:

  8A@125VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  125 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10.6 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  22.5mm x 16.5mm x 19mm

• Reference Standard:

  CSA; TUV; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  12.2 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
