G6A-234P-ST-US-DC6 - OMRON Electronics

G6A-234P-ST-US-DC6 Details

• Manufacturer Part Number:

  G6A-234P-ST-US-DC6

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  7.87

• Body Breadth:

  10.1 mm

• Body Height:

  8.4 mm

• Body Length or Diameter:

  20.2 mm

• Coil Current(DC)-Max:

  0.033 A

• Coil Operate Voltage(DC):

  4.2 V

• Coil Power:

  200 mW

• Coil Release Voltage(DC):

  0.6 V

• Coil Resistance:

  180 Ω

• Coil Voltage(DC)-Max:

  6 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .6A@125VAC

• Contact Current(AC)-Max:

  0.6 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@30VDC

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  5.5 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  20.2mm x 10.1mm x 8.4mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  3.5 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
