G6KU-2F-RF-TDC5 - OMRON Electronics

G6KU-2F-RF-TDC5 Details

• Manufacturer Part Number:

  G6KU-2F-RF-TDC5

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  8

• Body Breadth:

  6.9 mm

• Body Height:

  5.4 mm

• Body Length or Diameter:

  10.7 mm

• Characteristic Impedance:

  50 Ω

• Coil Current(DC)-Max:

  0.021 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  100 mW

• Coil Release Voltage(DC):

  3.75 V

• Coil Resistance:

  237 Ω

• Coil Voltage(DC)-Max:

  7.5 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  1A@125VAC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@60VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  60 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Input Power-Max:

  1 W

• Input Switching Control Type:

  Random

• Insertion Loss-Max:

  0.6 dB

• Insulation Resistance:

  1000000000 Ω

• Isolation-Max:

  25 dB

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Terminals:

  18

• Operate Time:

  3 ms

• Operating Frequency-Max:

  3000 MHz

• Operating Frequency-Min:

  1000 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, EMBOSSED, 13 INCH

• Physical Dimension:

  10.7mm x 6.9mm x 5.4mm

• Relay Action:

  LATCHED

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Release Time:

  3 ms

• Surface Mount:

  NO

• Switching Time:

  6 ms

• Terminal Finish:

  Tin (Sn)

• Termination Type:

  SOLDER

• VSWR:

  1.4
