G6S-2-YDC4.5 - OMRON Electronics

G6S-2-YDC4.5 Details

• Manufacturer Part Number:

  G6S-2-YDC4.5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  6.3

• Body Breadth:

  7.3 mm

• Body Height:

  9.2 mm

• Body Length or Diameter:

  14.8 mm

• Coil Current(DC)-Max:

  0.045 A

• Coil Operate Voltage(DC):

  3.375 V

• Coil Power:

  200 mW

• Coil Release Voltage(DC):

  0.45 V

• Coil Resistance:

  101 Ω

• Coil Voltage(DC)-Max:

  4.5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .5A@125VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Rating R Load:

  2A@30VDC

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  4.5 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TUBE

• Physical Dimension:

  14.8mm x 7.3mm x 9.2mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  4.5 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
