G7L-2A-P-CB-DC12 - OMRON Electronics

G7L-2A-P-CB-DC12 Details

• Manufacturer Part Number:

  G7L-2A-P-CB-DC12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  6.87

• Body Breadth:

  35.5 mm

• Body Height:

  47 mm

• Body Length or Diameter:

  52.5 mm

• Coil Current(DC)-Max:

  0.16 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  1900 mW

• Coil Release Voltage(DC):

  1.8 V

• Coil Resistance:

  75 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  20A@220VAC

• Contact Current(AC)-Max:

  20 A

• Contact Voltage(AC)-Max:

  220 V

• Contact/Output Supply Type:

  AC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Operate Time:

  30 ms

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -25 °C

• Physical Dimension:

  52.5mm x 35.5mm x 47mm

• Reference Standard:

  CE; CSA; TUV; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  DPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  30 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
