G8P-1A4P-DC5 - OMRON Electronics

G8P-1A4P-DC5 Details

• Manufacturer Part Number:

  G8P-1A4P-DC5

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  0

• Body Breadth:

  27.7 mm

• Body Height:

  20.1 mm

• Body Length or Diameter:

  32.1 mm

• Coil Current(DC)-Max:

  0.185 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  900 mW

• Coil Release Voltage(DC):

  0.5 V

• Coil Resistance:

  27 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  30A@250VAC

• Contact Current(AC)-Max:

  30 A

• Contact Current(DC)-Max:

  20 A

• Contact (DC) Max Rating R Load:

  20A@28VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  32.1mm x 27.7mm x 20.1mm

• Reference Standard:

  CSA; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
