G8V-RH-1A7T-R-DC12 - OMRON Electronics

G8V-RH-1A7T-R-DC12 Details

• Manufacturer Part Number:

  G8V-RH-1A7T-R-DC12

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Manufacturer:

  OMRON Electronic Components

• YTEOL:

  0

• Body Breadth:

  15 mm

• Body Height:

  25 mm

• Body Length or Diameter:

  22.5 mm

• Coil Current(DC)-Max:

  0.097 A

• Coil Operate Voltage(DC):

  7.5 V

• Coil Power:

  1600 mW

• Coil Release Voltage(DC):

  1 V

• Coil Resistance:

  124 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Voltage(AC)-Max:

  16 V

• Contact Voltage(DC)-Max:

  16 V

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Operate Time:

  20 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  22.5mm x 15mm x 25mm

• Relay Action:

  MOMENTARY

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  20 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
