The recommended PCB footprint for the GBU25H08-M3/P is a rectangular pad with a size of 2.5 mm x 1.5 mm, with a 0.5 mm radius corner and a 0.3 mm spacing between pads.
To handle thermal management, ensure good thermal conductivity between the device and the PCB by using a thermal pad or a thermal interface material. Also, consider using a heat sink or a thermal management system to dissipate heat generated by the device.
The maximum operating temperature range for the GBU25H08-M3/P is -55°C to 150°C, with a storage temperature range of -55°C to 175°C.
To ensure reliability, follow proper handling and storage procedures, use a clean and dry environment, and avoid exposing the device to mechanical stress, moisture, or extreme temperatures. Also, consider using a hermetically sealed package or a conformal coating to protect the device from environmental factors.
The GBU25H08-M3/P has an ESD rating of Human Body Model (HBM) ≥ 2 kV and Charged Device Model (CDM) ≥ 1 kV. To ensure ESD protection, use proper handling and storage procedures, and consider using ESD protection devices or circuits in the application.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
GBU25H08-M3/P Overview
Use the download button to access the GBU25H08-M3/P schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like GBU25,
or try a keyword search, such as Bridge Rectifier Diodes
