GS4288C36GL-18 - GSI TECHNOLOGY

GS4288C36GL-18 Details

• Manufacturer Part Number:

  GS4288C36GL-18

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  BGA

• Package Description:

  ROHS COMPLIANT, UBGA-144

• Pin Count:

  144

• Country Of Origin:

  Taiwan

• ECCN Code:

  3A991.B.2.B

• HTS Code:

  8542.32.00

• Manufacturer:

  GSI Technology

• YTEOL:

  4

• Access Mode:

  MULTI BANK PAGE BURST

• Additional Feature:

  AUTO REFRESH

• JESD-30 Code:

  R-PBGA-B144

• JESD-609 Code:

  e1

• Memory Density:

  301989888 bit

• Memory IC Type:

  DDR DRAM

• Memory Width:

  36

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Ports:

  1

• Number of Terminals:

  144

• Number of Words:

  8388608 words

• Number of Words Code:

  8000000

• Operating Mode:

  SYNCHRONOUS

• Organization:

  8MX36

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TBGA

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, THIN PROFILE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  1.2 mm

• Supply Voltage-Max (Vsup):

  1.9 V

• Supply Voltage-Min (Vsup):

  1.7 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  11 mm
