GXO-U115L/BI3.68640MHZ Details

• Manufacturer Part Number:

  GXO-U115L/BI3.68640MHZ

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CERAMIC PACKAGE-4

• Manufacturer:

  Golledge Electronics Ltd

• YTEOL:

  5

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION; TR

• Fall Time-Max:

  7 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  3.6864 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCMOS/LSTTL

• Output Load:

  10 LS TTL, 15 pF

• Physical Dimension:

  5.2mm x 3.4mm x 1.05mm

• Rise Time-Max:

  7 ns

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  60/40 %

• Terminal Finish:

  Gold (Au)
