HD6417713FV - Renesas Electronics

HD6417713FV Details

• Manufacturer Part Number:

  HD6417713FV

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  HFQFP

• Package Description:

  28 X 28 MM, 0.40 MM PITCH, PLASTIC, HQFP-256

• Pin Count:

  256

• Manufacturer Package Code:

  PRQP0256LA

• ECCN Code:

  3A991.a.2

• HTS Code:

  8542.31.00.25

• Manufacturer:

  Renesas Electronics Corporation

• Has ADC:

  NO

• Additional Feature:

  IT ALSO REQUIRES 3.3V I/O SUPPLY

• Address Bus Width:

  26

• Bit Size:

  32

• Clock Frequency-Max:

  66.67 MHz

• DAC Channels:

  NO

• DMA Channels:

  YES

• External Data Bus Width:

  32

• JESD-30 Code:

  S-PQFP-G256

• Length:

  28 mm

• Moisture Sensitivity Level:

  3

• Number of I/O Lines:

  24

• Number of Terminals:

  256

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -20 °C

• PWM Channels:

  NO

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FQFP

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, FINE PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  3.95 mm

• Speed:

  200 MHz

• Supply Voltage-Max:

  1.6 V

• Supply Voltage-Min:

  1.4 V

• Supply Voltage-Nom:

  1.5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Width:

  28 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER, RISC
