HE751B0500 - LITTELFUSE

HE751B0500 Details

• Manufacturer Part Number:

  HE751B0500

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  0

• Body Breadth:

  7.24 mm

• Body Height:

  7.5 mm

• Body Length or Diameter:

  19.05 mm

• Coil Operate Voltage(DC):

  3.75 V

• Coil Release Voltage(DC):

  0.5 V

• Coil Resistance:

  500 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Input Switching Control Type:

  Random

• Number of Terminals:

  4

• Operate Time:

  1 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  19.05mm x 7.24mm x 7.5mm

• Relay Form:

  1 FORM B

• Relay Function:

  SPST

• Release Time:

  1 ms

• Sealing:

  HERMETICAL

• Terminal Length:

  0.002999745999491999 inch

• Termination Type:

  SOLDER
