HF105F-1/220A-1HT - Hongfa

HF105F-1/220A-1HT Details

• Manufacturer Part Number:

  HF105F-1/220A-1HT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• Body Breadth:

  27.1 mm

• Body Height:

  20 mm

• Body Length or Diameter:

  32.3 mm

• Coil Current(AC)-Max:

  0.008 A

• Coil Operate Voltage(AC):

  176 V

• Coil Operate Voltage(DC):

  176 V

• Coil Power:

  1700 mW

• Coil Release Voltage(AC):

  44 V

• Coil Release Voltage(DC):

  44 V

• Coil Resistance:

  13490 Ω

• Coil Voltage(AC)-Max:

  220 V

• Coil Voltage-Nom:

  220 V

• Coil/Input Supply Type:

  AC

• Contact (AC) Max Power Rating R Load:

  7200VA@240VAC

• Contact (AC) Max Rating R Load:

  30A@240VAC

• Contact Current(AC)-Max:

  30 A

• Contact Current(DC)-Max:

  20 A

• Contact (DC) Max Power Rating R Load:

  560W@28VDC

• Contact (DC) Max Rating R Load:

  20A@28VDC

• Contact Resistance:

  50 mΩ

• Contact Voltage(AC)-Max:

  240 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  Silver Tin Oxide

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  4

• Operate Time:

  15 ms

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  32.3mm x 27.1mm x 20mm

• Reference Standard:

  CUL; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Sealing:

  DUST PROOF

• Surface Mount:

  NO

• Terminal Length:

  0.003599187198374397 inch

• Termination Type:

  SOLDER
