HHXJ350ARA181MHA0G - Chemi-Con

HHXJ350ARA181MHA0G Details

• Manufacturer Part Number:

  HHXJ350ARA181MHA0G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.20

• Manufacturer:

  Chemi-Con

• YTEOL:

  7.75

• Additional Feature:

  ESR IS MEASURED AT 100 KHZ

• Capacitance:

  180 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  8 mm

• Dielectric Material:

  ALUMINUM (SOLID POLYMER)

• ESR:

  22 mΩ

• Height:

  10 mm

• JESD-609 Code:

  e6

• Leakage Current:

  0.063 mA

• Length:

  8.3 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Style:

  SMT

• Packing Method:

  TR, 15 INCH

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  35 V

• Reference Standard:

  AEC-Q200

• Ripple Current:

  300 mA

• Size Code:

  3333

• Surface Mount:

  YES

• Tan Delta:

  0.12

• Terminal Finish:

  Tin/Bismuth (Sn/Bi)

• Terminal Shape:

  FLAT

• Width:

  8.3 mm
