HM5113165FLTD-6 - HITACHI

HM5113165FLTD-6 Details

• Manufacturer Part Number:

  HM5113165FLTD-6

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TSOP2

• Package Description:

  0.400 INCH, PLASTIC, TSOP2-50

• Pin Count:

  50

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.02

• Manufacturer:

  Hitachi Ltd

• YTEOL:

  0

• Access Mode:

  EDO PAGE

• Access Time-Max:

  60 ns

• Additional Feature:

  RAS ONLY/CAS BEFORE RAS/HIDDEN REFRESH/BATTERY BACKUP/SELF REFRESH

• I/O Type:

  COMMON

• JESD-30 Code:

  R-PDSO-G50

• JESD-609 Code:

  e0

• Length:

  20.95 mm

• Memory Density:

  134217728 bit

• Memory IC Type:

  EDO DRAM

• Memory Width:

  16

• Number of Functions:

  1

• Number of Ports:

  1

• Number of Terminals:

  50

• Number of Words:

  8388608 words

• Number of Words Code:

  8000000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  8MX16

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSOP2

• Package Equivalence Code:

  TSOP50,.46,32

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE

• Qualification Status:

  Not Qualified

• Refresh Cycles:

  4096

• Seated Height-Max:

  1.2 mm

• Self Refresh:

  YES

• Standby Current-Max:

  0.0005 A

• Supply Current-Max:

  0.23 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  DUAL

• Width:

  10.16 mm
