HPM10-W29A100G - onsemi

Description: Battery Type Flexibility: Automatically detects and charges rechargeable batteries (incl. Silver-Zinc (AgZn) and Lithium Ion). Also detects Zinc-Air (Zn-Air) and Nickel-Metal Hydride (Ni-Mh) disposable batteries.; High-Efficiency Power Regulation: Optimized regulators to minimize dissipated power from the battery to the hearing aid.; Ultra-Low Power Consumption: Offers a Deep Sleep current consumption of 15 nA to maximize the shelf life of a sealed battery; Non-Volatile Memory (OTP): Stores charging paramet

Download HPM10-W29A100G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
HPM10-W29A100G - onsemi - PCB symbol
click to zoom
PCB Footprints
HPM10-W29A100G - onsemi PCB footprint - Other - Other - WLCSP29 2.05x1.74x0.417 CASE 567MK ISSUE A
click to zoom
3D Models
HPM10-W29A100G - onsemi - 3D model - Other - WLCSP29 2.05x1.74x0.417 CASE 567MK ISSUE A
click to zoom

HPM10-W29A100G Details

  • Manufacturer Part Number:

    HPM10-W29A100G

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    WLCSP-29

  • Package Description:

    VFBGA,

  • Manufacturer Package Code:

    567MK

  • Reach Compliance Code:

    Compliant

  • Country Of Origin:

    USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    23 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    7

  • Additional Feature:

    TERM PITCH-MAX; ALSO HAS BATTERY SUPPLY VOLTAGE RANGES FROM 1 TO 6 V

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    INTEGRATED POWER MANAGEMENT UNIT

  • JESD-30 Code:

    R-PBGA-B29

  • Length:

    2.05 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    29

  • Operating Temperature-Max:

    50 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VFBGA

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.46 mm

  • Supply Voltage-Max (Vsup):

    5.2 V

  • Supply Voltage-Min (Vsup):

    4.8 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Temperature Grade:

    COMMERCIAL

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    1.74 mm
