HR1001AGS-Z - Monolithic Power Systems (MPS)

Description: AC/DC Converters Enhanced LLC Cntrlr W/Adaptve DT Control

Download HR1001AGS-Z Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
HR1001AGS-Z - Monolithic Power Systems (MPS) PCB footprint - Small Outline Packages - Small Outline Packages - SOIC-16
click to zoom
3D Models
HR1001AGS-Z - Monolithic Power Systems (MPS)  - 3D model - Small Outline Packages - SOIC-16
click to zoom

HR1001AGS-Z Details

  • Manufacturer Part Number:

    HR1001AGS-Z

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOIC-16

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    24 Weeks

  • Manufacturer:

    Monolithic Power Systems

  • Additional Feature:

    For BST, HG, SW Pins ESD VALUE=2

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Technique:

    RESONANT CONTROL

  • Input Voltage-Max:

    15.5 V

  • Input Voltage-Min:

    13 V

  • Input Voltage-Nom:

    13 V

  • JESD-30 Code:

    R-PDSO-G16

  • Length:

    9.9 mm

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Packing Method:

    TR

  • Seated Height-Max:

    1.75 mm

  • Supply Current-Max (Isup):

    5 mA

  • Supply Voltage-Nom (Vsup):

    13 V

  • Surface Mount:

    YES

  • Switching Frequency-Max:

    600 kHz

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

HR1001AGS-Z Frequently Asked Questions (FAQs)

  • A 2-layer or 4-layer PCB with a solid ground plane and thermal vias under the IC is recommended. Keep the input and output capacitors close to the IC and use short, wide traces for the power paths.
  • Ensure the output capacitor has a low ESR, use a minimum of 10uF output capacitance, and add a 1-2nF ceramic capacitor in parallel with the output capacitor to improve stability.
  • The maximum input voltage is 18V, but it's recommended to keep the input voltage below 15V to ensure reliable operation and minimize power dissipation.
  • The HR1001AGS-Z is rated for operation up to 125°C, but derating is required above 85°C. Ensure proper thermal design and consider using a heat sink if operating in high-temperature environments.
  • Use the formula: Pd = (Vin - Vout) x Iout x Efficiency. Consult the datasheet for efficiency curves and thermal resistance values to estimate power dissipation.
