HS1-1840AEH-Q - Renesas Electronics

HS1-1840AEH-Q Details

• Manufacturer Part Number:

  HS1-1840AEH-Q

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SBDIP

• Package Description:

  DIE-26

• Pin Count:

  28

• Manufacturer Package Code:

  D28.6

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  7

• Analog IC - Other Type:

  SINGLE-ENDED MULTIPLEXER

• JESD-30 Code:

  R-XUUC-N26

• JESD-609 Code:

  e4

• Length:

  35.6 mm

• Neg Supply Voltage-Max (Vsup):

  -16 V

• Neg Supply Voltage-Min (Vsup):

  -15 V

• Neg Supply Voltage-Nom (Vsup):

  -15.5 V

• Number of Channels:

  16

• Number of Functions:

  1

• Number of Terminals:

  26

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output:

  COMMON OUTPUT

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIE

• Package Equivalence Code:

  DIE OR CHIP

• Package Shape:

  RECTANGULAR

• Package Style:

  UNCASED CHIP

• Screening Level:

  MIL-PRF-38535 Class Q

• Seated Height-Max:

  2.41 mm

• Supply Voltage-Max (Vsup):

  16 V

• Supply Voltage-Min (Vsup):

  15 V

• Supply Voltage-Nom (Vsup):

  15.5 V

• Surface Mount:

  YES

• Switching:

  BREAK-BEFORE-MAKE

• Technology:

  BICMOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  2.5 mm

• Terminal Position:

  UPPER

• Total Dose:

  300k Rad(Si) V

• Width:

  15.1 mm
