HSP061-8M16 - STMicroelectronics

HSP061-8M16 Details

• Manufacturer Part Number:

  HSP061-8M16

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFN

• Package Description:

  3.30 X 1.50 MM, 0.55 MM HEIGHT, ROHS COMPLIANT, PLASTIC, UQFN-16

• Pin Count:

  16

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Additional Feature:

  LOW CAPACITANCE

• Breakdown Voltage-Min:

  6 V

• Clamping Voltage-Max:

  14 V

• Configuration:

  SINGLE, 8 CHANNEL

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-N16

• JESD-609 Code:

  e4

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Qualification Status:

  Not Qualified

• Reference Standard:

  IEC-61000-4-2; MIL-STD-883G

• Rep Pk Reverse Voltage-Max:

  3 V

• Reverse Current-Max:

  0.1 µA

• Reverse Test Voltage:

  3 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  NICKEL PALLADIUM GOLD

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30
