HV2607T-C/R8X - Microchip

HV2607T-C/R8X Details

• Manufacturer Part Number:

  HV2607T-C/R8X

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Pin Count:

  48

• Manufacturer Package Code:

  LQFP-48

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  19

• Additional Feature:

  ALSO REQUIRES 4.5 TO 6.3 V SUPPLY

• Analog IC - Other Type:

  SPDT

• Input Voltage-Max:

  100 V

• Input Voltage-Min:

  -100 V

• JESD-30 Code:

  S-PQFP-G48

• JESD-609 Code:

  e3

• Length:

  7 mm

• Neg Supply Voltage-Max (Vsup):

  -6.3 V

• Neg Supply Voltage-Min (Vsup):

  -4.5 V

• Number of Channels:

  16

• Number of Functions:

  1

• Number of Terminals:

  48

• Off-state Isolation-Nom:

  64 dB

• On-state Resistance Match-Nom:

  5.75 Ω

• On-state Resistance-Max (Ron):

  23 Ω

• Operating Temperature-Max:

  70 °C

• Output:

  SEPARATE OUTPUT

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFQFP

• Package Equivalence Code:

  QFP48,.35SQ,20

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, LOW PROFILE, FINE PITCH

• Seated Height-Max:

  1.6 mm

• Signal Current-Max:

  0.5 A

• Supply Current-Max (Isup):

  0.5 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Switch-off Time-Max:

  5000 ns

• Switch-on Time-Max:

  5000 ns

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  7 mm
