i6A4W010A033V-001-R - TDK Lambda

i6A4W010A033V-001-R Details

• Manufacturer Part Number:

  I6A4W010A033V-001-R

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  PACKAGE-34/11

• ECCN Code:

  EAR99

• Manufacturer:

  TDK-Lambda Corporation

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  97.5%

• Input Voltage-Max:

  53 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  8 V

• JESD-30 Code:

  R-XDMA-P11

• Length:

  33 mm

• Line Regulation-Max:

  0.3%

• Load Regulation-Max:

  0.9%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  11

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  10 A

• Output Voltage-Max:

  40 V

• Output Voltage-Min:

  3.3 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OVER CURRENT

• Ripple Voltage (Main Out):

  0.0803 Vrms

• Seated Height-Max:

  12.1 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  250 W

• Trim/Adjustable Output:

  YES

• Width:

  22.9 mm
