ICE5LP2K-CM36ITR - Lattice Semiconductor

ICE5LP2K-CM36ITR Details

• Manufacturer Part Number:

  ICE5LP2K-CM36ITR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.31.00.01

• Manufacturer:

  Lattice Semiconductor Corporation

• YTEOL:

  7.6

• Combinatorial Delay of a CLB-Max:

  9 ns

• JESD-30 Code:

  S-PBGA-B36

• Length:

  2.5 mm

• Moisture Sensitivity Level:

  3

• Number of CLBs:

  256

• Number of Inputs:

  26

• Number of Logic Cells:

  2048

• Number of Outputs:

  26

• Number of Terminals:

  36

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  256 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA36,6X6,16

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  260

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  0.91 mm

• Supply Voltage-Max:

  1.26 V

• Supply Voltage-Min:

  1.14 V

• Supply Voltage-Nom:

  1.2 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  2.5 mm
