IDDD04G65C6XTMA1 - Infineon

IDDD04G65C6XTMA1 Details

• Manufacturer Part Number:

  IDDD04G65C6XTMA1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Additional Feature:

  PD-CASE

• Application:

  EFFICIENCY

• Breakdown Voltage-Min:

  650 V

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON CARBIDE

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.35 V

• JESD-30 Code:

  R-PDSO-G10

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  29 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  13 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Power Dissipation-Max:

  56 W

• Rep Pk Reverse Voltage-Max:

  650 V

• Reverse Current-Max:

  14 µA

• Reverse Test Voltage:

  420 V

• Surface Mount:

  YES

• Technology:

  SCHOTTKY

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
