IL514E - NVE

Description: DGTL ISO 2.5KV GEN PURP 16SOIC

Download IL514E Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
IL514E - NVE PCB footprint - Small Outline Packages - Small Outline Packages - True 8™ 0.3" SOIC-16 Package (no suffix)
click to zoom
3D Models
IL514E - NVE  - 3D model - Small Outline Packages - True 8™ 0.3" SOIC-16 Package (no suffix)
click to zoom
  • Datasheet Download Datasheet
  • Stock & Prices $ Price & Stock for IL514E
  • Part Number IL514E
  • Manufacturer NVE
  • Pin Count 16
  • Part Category Integrated Circuit
  • Package Category Small Outline Packages
  • Footprint Name Small Outline Packages - True 8™ 0.3" SOIC-16 Package (no suffix)
  • Released Date Dec 18, 2021
  • Last Modified Date Mar 7, 2023 4:10 PM UTC
  • Pinout / Pin List Click Here (Member Only)

IL514E Details

  • Manufacturer Part Number:

    IL514E

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SOIC

  • Package Description:

    SOIC-16

  • Pin Count:

    16

  • Country Of Origin:

    USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    NVE Corporation

IL514E Frequently Asked Questions (FAQs)

  • NVE recommends a symmetrical PCB layout with the IL514E at the center, and keeping the signal traces as short as possible to minimize noise and interference. A 4-layer PCB with a solid ground plane is also recommended.
  • To ensure reliable operation in high-temperature environments, NVE recommends following proper thermal management practices, such as providing adequate heat sinking and airflow, and using a thermally conductive material for the PCB. Additionally, the IL514E is rated for operation up to 125°C, but derating may be necessary for extended operation at high temperatures.
  • The maximum allowable voltage on the VCC pin of the IL514E is 5.5V. Exceeding this voltage can cause permanent damage to the device.
  • To troubleshoot issues with the IL514E, NVE recommends checking the power supply voltage, ensuring proper PCB layout and routing, and verifying that the input signals are within the specified voltage ranges. Additionally, using an oscilloscope to monitor the input and output signals can help identify the source of the issue.
  • Yes, the IL514E is compatible with lead-free soldering processes. NVE recommends following the recommended soldering profile and using a lead-free solder alloy with a melting point of 217°C or higher.
