ILD6070 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  Infineon recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness and a thermal via array are also recommended.
• How do I ensure reliable operation at high temperatures?
  Infineon suggests using a thermal interface material (TIM) with a thermal conductivity of at least 1 W/mK between the device and the heat sink. Additionally, ensure the heat sink is properly attached and the system is designed to operate within the specified junction temperature range.
• What is the maximum allowed voltage on the input pins?
  Although the datasheet specifies a maximum input voltage of 5.5V, Infineon recommends limiting the input voltage to 5V to ensure reliable operation and prevent damage to the device.
• How do I handle ESD protection during handling and assembly?
  Infineon recommends following standard ESD handling procedures, such as using ESD-protective packaging, wrist straps, and mats. Additionally, ensure that the device is handled in a humidity-controlled environment to prevent moisture-related damage.
• What is the recommended soldering profile for the ILD6070?
  Infineon suggests using a soldering profile with a peak temperature of 260°C (500°F) and a dwell time of 30-60 seconds. A soldering iron with a temperature range of 350-400°C (662-752°F) is also recommended.
