IM513-L6A - Infineon

IM513-L6A Details

• Manufacturer Part Number:

  IM513-L6A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  MODULE-24

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Analog IC - Other Type:

  AC MOTOR CONTROLLER

• JESD-30 Code:

  R-XZFM-T24

• Number of Functions:

  1

• Number of Terminals:

  24

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  12 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  ZFM

• Package Equivalence Code:

  ZIP24,.17TB

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Supply Current-Max (Isup):

  0.9 mA

• Supply Voltage-Max (Vsup):

  18.5 V

• Supply Voltage-Min (Vsup):

  14 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  ZIG-ZAG
