IMBG120R045M1H - Infineon

IMBG120R045M1H Details

• Manufacturer Part Number:

  IMBG120R045M1H

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Austria, Malaysia

• ECCN Code:

  EAR99

• Date Of Intro:

  2020-09-17

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  7

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE AND KELVIN SENSOR

• DS Breakdown Voltage-Min:

  1200 V

• Drain Current-Max (ID):

  47 A

• Drain-source On Resistance-Max:

  0.08 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  7.3 pF

• JEDEC-95 Code:

  TO-263

• JESD-30 Code:

  R-PSSO-G7

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  7

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  227 W

• Pulsed Drain Current-Max (IDM):

  119 A

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON CARBIDE
