INA101KU - BURR-BROWN

INA101KU Details

• Manufacturer Part Number:

  INA101KU

• Part Life Cycle Code:

  Transferred

• Package Description:

  SOL-16

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Burr-Brown Corp

• Amplifier Type:

  INSTRUMENTATION AMPLIFIER

• Average Bias Current-Max (IIB):

  0.03 µA

• Bandwidth (3dB)-Nom:

  0.3 MHz

• Common-mode Reject Ratio-Min:

  65 dB

• Input Offset Current-Max (IIO):

  0.03 µA

• Input Offset Voltage-Max:

  1150 µV

• JESD-30 Code:

  R-PDSO-G16

• JESD-609 Code:

  e0

• Neg Supply Voltage Limit-Max:

  -20 V

• Neg Supply Voltage-Nom (Vsup):

  -15 V

• Non-linearity-Max:

  0.025%

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP16,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Slew Rate-Nom:

  0.4 V/us

• Supply Current-Max:

  17 mA

• Supply Voltage Limit-Max:

  20 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Voltage Gain-Max:

  1000

• Voltage Gain-Min:

  1

• Voltage Gain-Nom:

  100
