IP4283CZ10-TBA - NXP

IP4283CZ10-TBA Details

• Manufacturer Part Number:

  IP4283CZ10-TBA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  SON

• Package Description:

  2.50 X 1 MM, 0.50 MM HEIGHT, HALOGEN FREE AND ROHS COMPLIANT, PLASTIC, XSON-10

• Pin Count:

  10

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  NXP Semiconductors

• Additional Feature:

  LOW CAPACITANCE

• Breakdown Voltage-Max:

  9 V

• Breakdown Voltage-Min:

  6 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-N10

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  10

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Technology:

  ZENER

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30
