IPL60R360P6SATMA1 - Infineon

Description: MOSFET N-Ch 600V 11.3A ThinPAK 5x6

Download IPL60R360P6SATMA1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
IPL60R360P6SATMA1 - Infineon PCB footprint - Other - Other - ThinPAK5x6SMD
click to zoom
3D Models
IPL60R360P6SATMA1 - Infineon  - 3D model - Other - ThinPAK5x6SMD
click to zoom

IPL60R360P6SATMA1 Details

  • Manufacturer Part Number:

    IPL60R360P6SATMA1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Package Description:

    6 X 5 MM, HALOGEN FREE AND ROHS COMPLIANT, THINPAK-5

  • Country Of Origin:

    Germany, Malaysia

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    15 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    0

  • Avalanche Energy Rating (Eas):

    247 mJ

  • Case Connection:

    DRAIN

  • Configuration:

    SINGLE WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    600 V

  • Drain-source On Resistance-Max:

    0.36 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • JESD-30 Code:

    R-PDSO-N5

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    1

  • Number of Terminals:

    5

  • Operating Mode:

    ENHANCEMENT MODE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Polarity/Channel Type:

    N-CHANNEL

  • Pulsed Drain Current-Max (IDM):

    30 A

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

IPL60R360P6SATMA1 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the IPL60R360P6SATMA1 is -40°C to 150°C.
  • Proper cooling can be achieved by using a heat sink with a thermal resistance of ≤ 0.5 K/W, and ensuring good thermal contact between the IGBT and heat sink.
  • The recommended gate resistor value for the IPL60R360P6SATMA1 is between 10 Ω to 100 Ω, depending on the specific application and switching frequency.
  • Yes, the IPL60R360P6SATMA1 can be used in a parallel configuration, but it's essential to ensure that the IGBTs are matched and the gate drive circuits are properly synchronized.
  • The maximum allowable voltage transient for the IPL60R360P6SATMA1 is ±10% of the maximum rated voltage (600V).
