IPT1-125-07-L-D-PL Frequently Asked Questions (FAQs)

• What is the recommended mating sequence for this connector?
  The recommended mating sequence for IPT1-125-07-L-D-PL is to mate the plug (IPT1-125-07-L-D-PL) to the receptacle (IPT1-125-07-L-S-PL) by aligning the keying features and gently pushing them together until they click into place.
• Can I use this connector in a high-vibration environment?
  Yes, the IPT1-125-07-L-D-PL is designed to withstand high-vibration environments. Samtec's IPT series connectors are tested to meet the requirements of IEC 61373 Cat. 2, which includes vibration testing up to 15g.
• What is the maximum operating temperature for this connector?
  The maximum operating temperature for the IPT1-125-07-L-D-PL is 125°C. However, it's recommended to derate the current carrying capacity of the connector at higher temperatures to ensure reliable operation.
• Can I use this connector in a humid or wet environment?
  The IPT1-125-07-L-D-PL has a sealed construction that provides some level of protection against moisture. However, it's not designed for immersion in water or exposure to high-pressure water jets. If you need a connector for a wet environment, consider using a connector with a higher IP rating or additional sealing measures.
• What is the recommended torque for the screw locks on this connector?
  The recommended torque for the screw locks on the IPT1-125-07-L-D-PL is 0.5 N·m to 1.5 N·m. Over-torquing can damage the connector or the PCB, so it's essential to follow the recommended torque specification.
