ISA16-3FBH-24.000MHZ - ABRACON

ISA16-3FBH-24.000MHZ Details

• Manufacturer Part Number:

  ISA16-3FBH-24.000MHZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  SMD, 4 PIN

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  0

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  6 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  24 MHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVCMOS

• Output Load:

  15 pF

• Package Body Material:

  METAL

• Package Equivalence Code:

  LCC4,.06X.08,54/42

• Physical Dimension:

  2.0mm x 1.6mm x 0.8mm

• Rise Time-Max:

  6 ns

• Screening Level:

  AEC-Q200; TS-16949

• Supply Current-Max:

  20 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  GOLD OVER NICKEL
