ISL71148SLHMNZ - Renesas Electronics

ISL71148SLHMNZ Details

• Manufacturer Part Number:

  ISL71148SLHMNZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFP-28

• ECCN Code:

  3A001.a.2.c

• HTS Code:

  8542.39.00.30

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  7

• Analog Input Voltage-Max:

  1.3 V

• Analog Input Voltage-Min:

  -1.2 V

• Conversion Time-Max:

  1.55 µs

• Converter Type:

  ADC, SUCCESSIVE APPROXIMATION

• JESD-30 Code:

  R-CDFP-F28

• Length:

  18.8 mm

• Linearity Error-Max (EL):

  0.012207%

• Number of Analog In Channels:

  8

• Number of Bits:

  14

• Number of Functions:

  1

• Number of Terminals:

  28

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Bit Code:

  2S COMPLEMENT BINARY

• Output Format:

  SERIAL

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DFP

• Package Equivalence Code:

  FL28,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK

• Sample Rate:

  0.9 MHz

• Seated Height-Max:

  2.92 mm

• Supply Current-Max:

  23 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  12.445 mm
