ISL73444SEHF/PROTO - Renesas Electronics

ISL73444SEHF/PROTO Details

• Manufacturer Part Number:

  ISL73444SEHF/PROTO

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  CFP

• Pin Count:

  14

• Manufacturer Package Code:

  K14.C

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  5.88

• Amplifier Type:

  OPERATIONAL AMPLIFIER

• Architecture:

  VOLTAGE-FEEDBACK

• Average Bias Current-Max (IIB):

  0.58 µA

• Common-mode Reject Ratio-Min:

  70 dB

• Common-mode Reject Ratio-Nom:

  92 dB

• Frequency Compensation:

  YES

• Input Offset Voltage-Max:

  500 µV

• JESD-30 Code:

  R-CDFP-F14

• JESD-609 Code:

  e4

• Length:

  9.73 mm

• Low-Bias:

  NO

• Low-Offset:

  YES

• Micropower:

  NO

• Neg Supply Voltage Limit-Max:

  -21 V

• Neg Supply Voltage-Nom (Vsup):

  -2.5 V

• Number of Functions:

  4

• Number of Terminals:

  14

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DFP

• Package Equivalence Code:

  FL14,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK

• Power:

  NO

• Programmable Power:

  NO

• Seated Height-Max:

  2.92 mm

• Slew Rate-Nom:

  35 V/us

• Supply Current-Max:

  9.6 mA

• Supply Voltage Limit-Max:

  21 V

• Supply Voltage-Nom (Vsup):

  2.5 V

• Surface Mount:

  YES

• Technology:

  SOI-CMOS

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  FLAT

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Unity Gain BW-Nom:

  17000

• Voltage Gain-Min:

  31622.7766

• Wideband:

  NO

• Width:

  6.45 mm
