ISL75052SEHFE/PROTO - Renesas Electronics

ISL75052SEHFE/PROTO Details

• Manufacturer Part Number:

  ISL75052SEHFE/PROTO

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  CFP

• Package Description:

  DFP-16

• Pin Count:

  16

• Manufacturer Package Code:

  K16.E

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  6.7

• Adjustability:

  ADJUSTABLE

• Dropout Voltage1-Max:

  0.4 V

• Dropout Voltage1-Nom:

  0.225 V

• JESD-30 Code:

  R-CDFP-F16

• JESD-609 Code:

  e4

• Length:

  10.414 mm

• Line Regulation-Max (%/V):

  0.037

• Load Regulation-Max(%):

  0.36%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  16

• Operating Temperature TJ-Max:

  150 °C

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Current1-Max:

  1.5 A

• Output Voltage1-Max:

  12.7 V

• Output Voltage1-Min:

  0.6 V

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DFP

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK

• Regulator Type:

  ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  2.92 mm

• Surface Mount:

  YES

• Technology:

  BICMOS

• Terminal Finish:

  GOLD

• Terminal Form:

  FLAT

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Total Dose:

  100k Rad(Si) V

• Width:

  6.855 mm
