ISM97-3251BH-24.000MHz - ABRACON

ISM97-3251BH-24.000MHz Details

• Manufacturer Part Number:

  ISM97-3251BH-24.000MHZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 4 PIN

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6.44

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  6 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  24 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CMOS

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  LCC4,.09X.12,86/69

• Physical Dimension:

  3.2mm x 2.5mm x 1.2mm

• Rise Time-Max:

  6 ns

• Supply Current-Max:

  20 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
