IWR1642AQAGABLR - Texas Instruments

Description: Single-chip 76-GHz to 81-GHz mmWave sensor integrating DSP and MCU

Download IWR1642AQAGABLR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
IWR1642AQAGABLR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
IWR1642AQAGABLR - Texas Instruments PCB footprint - BGA - BGA - ABL0161B
click to zoom
3D Models
IWR1642AQAGABLR - Texas Instruments - 3D model - BGA - ABL0161B
click to zoom

IWR1642AQAGABLR Details

  • Manufacturer Part Number:

    IWR1642AQAGABLR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Philippines, South Korea

  • ECCN Code:

    5A991.B.6.B

  • HTS Code:

    8542.31.00.75

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Additional Feature:

    Frequency range : 76 - 81 GHz

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-PBGA-B161

  • JESD-609 Code:

    e1

  • Length:

    10.4 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    161

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TFBGA

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY, THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.17 mm

  • Supply Voltage-Max (Vsup):

    1.32 V

  • Supply Voltage-Min (Vsup):

    1.14 V

  • Supply Voltage-Nom (Vsup):

    1.2 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    10.4 mm

IWR1642AQAGABLR Frequently Asked Questions (FAQs)

  • The maximum range of the IWR1642AQAGABLR is approximately 100 meters, depending on the antenna configuration and environmental conditions.
  • The IWR1642AQAGABLR uses a combination of frequency modulation and pulse compression to mitigate multipath interference. Additionally, the device's built-in signal processing algorithms can help to reduce the effects of multipath.
  • The minimum distance the IWR1642AQAGABLR can detect is approximately 0.5 meters, depending on the antenna configuration and environmental conditions.
  • Yes, the IWR1642AQAGABLR can be used for gesture recognition applications, such as detecting hand or finger movements. The device's high-resolution range and velocity data can be used to track the movement of objects and people.
  • The IWR1642AQAGABLR has built-in noise reduction and interference mitigation techniques, including adaptive thresholding and frequency hopping. Additionally, the device's signal processing algorithms can help to reduce the effects of noise and interference.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

IWR1642AQAGABLR Overview

Use the download button to access the IWR1642AQAGABLR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like IWR16, or try a keyword search, such as Other Signal Circuits

About Texas Instruments

Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
