IWR6443AQGABL - Texas Instruments

Description: RF System on a Chip - SoC Single-chip 60-GHz to 64-GHz intelligent mmWave sensor integrating MCU and hardware accelerator 161-FC/CSP -40 to 105

Download IWR6443AQGABL Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
IWR6443AQGABL - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
IWR6443AQGABL - Texas Instruments PCB footprint - BGA - BGA - ABL0161B
click to zoom
3D Models
IWR6443AQGABL - Texas Instruments - 3D model - BGA - ABL0161B
click to zoom

IWR6443AQGABL Details

  • Manufacturer Part Number:

    IWR6443AQGABL

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Philippines, South Korea

  • ECCN Code:

    5A991.B.6.B

  • HTS Code:

    8542.31.00.75

  • Date Of Intro:

    2020-06-07

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Additional Feature:

    Frequency range : 60 - 64 GHz

  • Body Breadth:

    10.4 mm

  • Body Height:

    1.17 mm

  • Body Length or Diameter:

    10.4 mm

  • JESD-609 Code:

    e1

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    161

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    OPEN-DRAIN

  • Output Range:

    0.45-1.35V

  • Output Type:

    DIGITAL VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    BGA161,15X15,26

  • Package Shape/Style:

    SQUARE

  • Sensors/Transducers Type:

    MMWAVE RADAR SENSOR MODULE

  • Supply Voltage-Max:

    1.32 V

  • Supply Voltage-Min:

    1.14 V

  • Surface Mount:

    YES

  • Technology:

    RFCMOS

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

IWR6443AQGABL Frequently Asked Questions (FAQs)

  • The maximum range of the IWR6443AQGABL radar sensor is approximately 100 meters, but it can be affected by various factors such as antenna design, frequency, and environmental conditions.
  • The IWR6443AQGABL uses a combination of techniques such as frequency hopping, spatial diversity, and adaptive filtering to mitigate multipath interference. Additionally, the device's built-in signal processing algorithms can help to reduce the impact of multipath effects.
  • Yes, the IWR6443AQGABL can be used for gesture recognition applications due to its high-resolution range and velocity data. The device's ability to detect micro-Doppler signatures enables it to recognize and track gestures, making it suitable for applications such as gesture-controlled interfaces.
  • The power consumption of the IWR6443AQGABL varies depending on the operating mode and frequency. In typical operating conditions, the device consumes around 1.5W to 2.5W. However, this can be reduced to around 100mW to 500mW in low-power modes.
  • Yes, the IWR6443AQGABL is part of the TI mmWave radar sensor family and shares a common API and software framework with other devices in the family. This makes it easier to integrate and develop applications that use multiple radar sensors.
