IXXK100N60C3H1 - LITTELFUSE

IXXK100N60C3H1 Details

• Manufacturer Part Number:

  IXXK100N60C3H1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  5.25

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  170 A

• Collector-Emitter Voltage-Max:

  600 V

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Gate-Emitter Thr Voltage-Max:

  5.5 V

• Gate-Emitter Voltage-Max:

  20 V

• JEDEC-95 Code:

  TO-264AA

• JESD-30 Code:

  R-PSFM-T3

• JESD-609 Code:

  e1

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  695 W

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  10

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  220 ns

• Turn-on Time-Nom (ton):

  95 ns

• VCEsat-Max:

  2.2 V
