IXXX100N75B4H1 - LITTELFUSE

IXXX100N75B4H1 Details

• Manufacturer Part Number:

  IXXX100N75B4H1

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  0

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  240 A

• Collector-Emitter Voltage-Max:

  750 V

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Gate-Emitter Thr Voltage-Max:

  6.5 V

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-PSIP-T3

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  880 W

• Surface Mount:

  NO

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  426 ns

• Turn-on Time-Nom (ton):

  67 ns

• VCEsat-Max:

  2.1 V
