IXYT40N120A4HV - LITTELFUSE

IXYT40N120A4HV Details

• Manufacturer Part Number:

  IXYT40N120A4HV

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  5.82

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  140 A

• Collector-Emitter Voltage-Max:

  1200 V

• Configuration:

  SINGLE

• Gate-Emitter Thr Voltage-Max:

  6.5 V

• Gate-Emitter Voltage-Max:

  20 V

• JEDEC-95 Code:

  TO-268AA

• JESD-30 Code:

  R-PSSO-G2

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  600 W

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  1040 ns

• Turn-on Time-Nom (ton):

  67 ns

• VCEsat-Max:

  1.8 V
