J105D1CS24VDC.45 - CIT Relay & Switch

J105D1CS24VDC.45 Details

• Manufacturer Part Number:

  J105D1CS24VDC.45

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  CIT Relay & Switch

• YTEOL:

  0

• Body Breadth:

  10.15 mm

• Body Height:

  15.75 mm

• Body Length or Diameter:

  20.59 mm

• Coil Current(DC)-Max:

  0.019 A

• Coil Operate Voltage(DC):

  18 V

• Coil Power:

  450 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  1280 Ω

• Coil Voltage(DC)-Max:

  31.2 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  2770VA@277VAC

• Contact (AC) Max Rating R Load:

  10A@277VAC

• Contact Current(AC)-Max:

  10 A

• Contact Resistance:

  50 mΩ

• Contact Voltage(AC)-Max:

  277 V

• Contact/Output Supply Type:

  AC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER TIN OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  5

• Operate Time:

  10 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  20.59mm x 10.15mm x 15.75mm

• Reference Standard:

  CUL; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Terminal Length:

  0.004000508001016002 inch

• Termination Type:

  SOLDER
