JM38510/17203BCA - Texas Instruments

Description: JM38510/17203BCA

Download JM38510/17203BCA Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
JM38510/17203BCA - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
JM38510/17203BCA - Texas Instruments PCB footprint - Ceramic Dual-In-Line Packages - Ceramic Dual-In-Line Packages - J0014A
click to zoom
3D Models
JM38510/17203BCA - Texas Instruments - 3D model - Ceramic Dual-In-Line Packages - J0014A
click to zoom

JM38510/17203BCA Details

  • Manufacturer Part Number:

    JM38510/17203BCA

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DIP

  • Package Description:

    CDIP-14

  • Pin Count:

    14

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Family:

    4000/14000/40000

  • JESD-30 Code:

    R-GDIP-T14

  • JESD-609 Code:

    e0

  • Length:

    19.43 mm

  • Load Capacitance (CL):

    50 pF

  • Logic IC Type:

    XOR GATE

  • Max I(ol):

    0.0015 A

  • Number of Functions:

    4

  • Number of Inputs:

    2

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -55 °C

  • Output Characteristics:

    TOTEM-POLE

  • Package Body Material:

    CERAMIC, GLASS-SEALED

  • Package Code:

    DIP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Packing Method:

    TUBE

  • Power Supply Current-Max (ICC):

    0.00075 mA

  • Prop. Delay@Nom-Sup:

    350 ns

  • Propagation Delay (tpd):

    280 ns

  • Qualification Status:

    Not Qualified

  • Schmitt Trigger:

    NO

  • Screening Level:

    MIL-M-38510 Class B

  • Seated Height-Max:

    5.08 mm

  • Supply Voltage-Max (Vsup):

    18 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    NO

  • Technology:

    CMOS

  • Temperature Grade:

    MILITARY

  • Terminal Finish:

    Tin/Lead (Sn/Pb)

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

JM38510/17203BCA Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for JM38510/17203BCA is -55°C to 125°C, as specified in the datasheet. However, it's essential to note that the device's performance and reliability may degrade if operated outside this range.
  • To ensure the reliability of JM38510/17203BCA in high-reliability applications, it's crucial to follow proper design, manufacturing, and testing procedures. This includes adhering to Texas Instruments' recommended operating conditions, using proper PCB layout and thermal management, and performing thorough testing and validation.
  • The maximum power dissipation for JM38510/17203BCA is not explicitly stated in the datasheet. However, based on the device's thermal resistance and maximum junction temperature, the maximum power dissipation can be calculated. It's recommended to consult with Texas Instruments' application engineers or perform thermal analysis to determine the maximum power dissipation for a specific application.
  • JM38510/17203BCA is not specifically designed or tested for radiation hardness. If radiation hardness is a requirement, it's recommended to consult with Texas Instruments' application engineers or consider using a radiation-hardened equivalent device.
  • The recommended storage temperature range for JM38510/17203BCA is -65°C to 150°C, as specified in the datasheet. It's essential to follow proper storage and handling procedures to prevent damage to the device.
