- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for JS1400DFQ
- Part Number JS1400DFQ
- Manufacturer E-Switch
- Pin Count 8
- Part Category Switch
- Package Category Other
- Last Modified Date Apr 23, 2025 12:12 PM UTC
- Pinout / Pin List Click Here (Member Only)
JS1400DFQ Details
-
Manufacturer Part Number:
JS1400DFQ
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
ECCN Code:
EAR99
-
HTS Code:
8536.50.70.00
-
Manufacturer:
E-Switch Inc
-
Switch Type:
NAVIGATOR SWITCH
JS1400DFQ Frequently Asked Questions (FAQs)
-
The recommended operating temperature range for the JS1400DFQ is -20°C to 85°C, although it can withstand storage temperatures from -40°C to 100°C.
-
To ensure proper debouncing, it's recommended to use an external debouncing circuit or a microcontroller with built-in debouncing capabilities. The datasheet provides guidance on debouncing circuit design.
-
The maximum current rating for the JS1400DFQ is 50mA at 12VDC. Exceeding this rating may lead to premature wear or failure.
-
Yes, the JS1400DFQ is designed to withstand high-vibration and high-shock environments, making it suitable for industrial, automotive, and aerospace applications.
-
Yes, the JS1400DFQ meets various automotive and industrial standards, including IEC 61076-2-1, IEC 61076-2-2, and RoHS compliance.
Trust Checks
Trust Score Unavailable
JS1400DFQ Overview
Use the download button to access the JS1400DFQ 3D model. You can still request or build the schematic symbol and PCB footprint by using the respective build or request forms on this page.
To find more CAD model downloads similar to this part, try a partial part number search, like JS140,
or try a keyword search, such as Special Switches
