The recommended land pattern for the KC355QD7LF224KH01L can be found in Murata's Capacitor Land Pattern document (PDF) or by contacting Murata's technical support.
The KC355QD7LF224KH01L is a moisture-sensitive device. It's essential to follow Murata's recommended storage and handling procedures to prevent moisture absorption. This includes storing the components in a dry environment, using desiccant packaging, and baking the components before use if they've been exposed to high humidity.
While the datasheet provides the ESR at 100 kHz, Murata may not provide ESR values at other frequencies in the datasheet. However, you can contact Murata's technical support or refer to their application notes for more information on ESR characteristics at different frequencies.
The KC355QD7LF224KH01L is a commercial-grade capacitor. For high-reliability or aerospace applications, you may need to use a capacitor that meets specific standards, such as MIL-PRF-123 or NASA-approved components. Murata offers specialized capacitors for these applications, and you should contact their technical support to discuss your specific requirements.
The SRF of the KC355QD7LF224KH01L can be determined using impedance analysis or by consulting Murata's application notes and technical documentation. You can also contact Murata's technical support for guidance on determining the SRF.
