KCDX-8S-N2 - Kycon

KCDX-8S-N2 Details

• Manufacturer Part Number:

  KCDX-8S-N2

• Part Life Cycle Code:

  Active Unconfirmed

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Kycon Inc

• YTEOL:

  2

• Board Mounting Option:

  LOCATING POSTS

• Body Breadth:

  0.768 inch

• Body Depth:

  0.748 inch

• Body Length:

  0.827 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  MINI DIN CONNECTOR

• Contact Finish Mating:

  TIN

• Contact Finish Termination:

  TIN

• Contact Gender:

  FEMALE

• Contact Style:

  BELLOWED TYPE

• DIN Conformance:

  YES

• EMI Shielded:

  NO

• IEC Conformance:

  NO

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE/POLYETHYLENE

• JESD-609 Code:

  e3

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  2 A

• Termination Type:

  SOLDER

• Total Number of Contacts:

  8
