KP219N3621 - Infineon

Description: Board Mount Pressure Sensors Analog Absolute Pressure Sensor

Download KP219N3621 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
KP219N3621 - Infineon PCB footprint - Other - Other - KP219N3621-1
click to zoom

KP219N3621 Details

  • Manufacturer Part Number:

    KP219N3621

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    11

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • Moisture Sensitivity Level:

    1

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED
