KW4-361CVA - Luckylight

Description: Display LED 7-segment 9.2mm 0.36" No.char 4 red 33÷66mcd ,20mA -40℃ to +80℃,5V

Download KW4-361CVA Model

Schematic
symbols

PCB
footprints

3D
models

Alert me if there are changes to this KW4-361CVA model

Email notifications will be applied after download.

Send part feedback

Symbol

KW4-361CVA - Luckylight - PCB symbol

PCB Footprints

KW4-361CVA - Luckylight PCB footprint - Other - Other - DIP-10_2026

3D Models

KW4-361CVA - Luckylight - 3D model - Other - DIP-10_2026

Datasheet Download Datasheet
Stock & Prices Price & Stock for KW4-361CVA
Part Number KW4-361CVA
Manufacturer Luckylight
Pin Count 12
Part Category Display
Package Category Other
Footprint Name Other - DIP-10_2026
Released Date Feb 10, 2026
Last Modified Date Feb 10, 2026 10:07 AM UTC
Pinout / Pin List Click Here (Member Only)

KW4-361CVA Details

Manufacturer Part Number:
KW4-361CVA
Manufacturer:
Lucky Light Electronics Co Ltd

Trust Checks

Community Provided

System Verified

Community Approved

KW4-361CVA Overview

Use the download button to access the KW4-361CVA schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like KW4-3, or try a keyword search, such as LED Displays
