L083S103LF Details

• Manufacturer Part Number:

  L083S103LF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8533.21.00.50

• Manufacturer:

  TT Electronics Resistors

• YTEOL:

  8

• Construction:

  Rectangular

• Element Power Dissipation:

  0.2 W

• First Element Resistance:

  10000 Ω

• JESD-609 Code:

  e1

• Lead Length:

  3.56 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Network Type:

  ISOLATED

• Number of Elements:

  1

• Number of Functions:

  4

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  5.08 mm

• Package Length:

  20.32 mm

• Package Shape:

  RECTANGULAR PACKAGE

• Package Style:

  SIP

• Package Width:

  2.5 mm

• Packing Method:

  Bulk

• Rated Power Dissipation (P):

  0.2 W

• Rated Temperature:

  70 °C

• Resistance:

  10000 Ω

• Resistor Type:

  ARRAY/NETWORK RESISTOR

• Second/Last Element Resistance:

  10000 Ω

• Surface Mount:

  NO

• Technology:

  METAL GLAZE/THICK FILM

• Temperature Coefficient:

  100 ppm/°C

• Temperature Coefficient Tracking:

  50 ppm/°C

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Shape:

  FLAT

• Tolerance:

  2%

• Working Voltage:

  100 V
